Kinki Studio - EX-P7 High resolution Pre Amplifier
The EX Series is tuned to reproduce sound quality with balance mid and smooth extension in both ends, high and low extension. True Class-A biased, fully discrete input and output stages are the heart of the EX-P7. Rich in tonal quality, details, and high resolution. Silky smooth volume control thanks to the discrete R2R volume control, of which known for its precise and accurate volume adjustment with precision matched resistors.
The EX Series is tuned to reproduce sound quality with balance mid and smooth extension in both ends, high and low extension. True Class-A biased, fully discrete input and output stages are the heart of the EX-P7. Rich in tonal quality, details, and high resolution. Silky smooth volume control thanks to the discrete R2R volume control, of which known for its precise and accurate volume adjustment with precision matched resistors.
The EX Series is tuned to reproduce sound quality with balance mid and smooth extension in both ends, high and low extension. True Class-A biased, fully discrete input and output stages are the heart of the EX-P7. Rich in tonal quality, details, and high resolution. Silky smooth volume control thanks to the discrete R2R volume control, of which known for its precise and accurate volume adjustment with precision matched resistors.
Technical specification
Paramteres
Frequency Response: 0-150kHz (±1dB)
THDN: 0.003% (-80dB)
S/N Ratio: >90dB
Channel Seperation: >90dB
Input/ Output
Input Sensitivity: 2.25Vrms - 3.6Vrms
Input Impedance: 50kΩ
Input Connector: RCA x 2, XLR x 1
Output Voltage: 2.25Vrms - 3.6Vrms
Output Impedance: 75Ω
Output Connector: RCA x 2, XLR x 1
Dimension & Weight
Dimension: 430W x 125H x 370D
Weight: 13KG
